Selenium Rectifier for Battery Charging
Selenium Rectifier for Battery Charging

Selenium Rectifier for Battery Charging

Any Questions?
+86-13720244449

Send Email
sales@semiduken.com

DESCRIPTION

 specifications        Selenium rectifier for battery charging

Input voltage

phase 380VAC-480VAC±10%,50HZ/60HZ

Output current

0-2000A

other 0-30000A as you need

Output voltage

0-480V

  other 0-1000V as you need

Output range

Output voltage:0~100% adjustable

Output current : 0~ 100% adjustable

Efficiency

  ≥90%

Control mode

switch mode,PWM pulse control

Cool mode

Forced by air cooling

Voltage stability

  within1%

Current stability

  within1%

Control accuracy

Rated value within±1%

Operation mode

Constant voltage ,Constant current ,output adjustment ,ON/OFF FORWARD/REVERSE POLARITY and so on .

Designed by your requirements



Work load

100% full load continuous running , If more than 1,000 meters above sea level,

it will be reduced load operation



Working condition



Indoors better with ambient Temperature range from -10 °C to 40 °C is good for device ,

Less than 90% humidity(when ambient temperature is 20°C±5°C)

Display

Digital meters

Extra function

PLC 4-20mA,0~5V,0~10V ,RS485  interface  Designed by your requirements



Polarity reversing , multi step timer ,ampere hour meter ,touch screen ,timer alarm soft start time control Designed by your requirements

Complete functions

The self-protection function of over current ,short circuit,overheating ,

phase lack ,etc .

Easy to maintain

Warranty

 At least 2 year from delivery against manufacturing defects, material defects

 and workmanship fails. Warranty does not cover mishandling, misuse and any operation outside working
